Standard Mills for Basic Grinding

Bottom discharge units for dependable crushing and grinding of most materials.

• Ideal for processing heavy or wet materials
• Sizes from 6" laboratory units to 60" wide industrial grinders suitable for mining operations
• Rotor configuration, RPM and screen size variable for optimum performance on your material
• Wide selection of hammer materials in swinging or fixed mounts
• Dust-tight or water-tight construction
• All stainless steel construction available for food, chemical or other applications
• Accepts both perforated and bar-type screens
• Mill-top metal traps at no extra charge
• Special configurations on request


Some Examples:

Model	Rotor Diameter	Typical Horsepower	Mill Speed (Maximum Rotor RPM)
W-6-L	9"	2	5,000
W-8-L	9"	3	5,000
W-8-H	16"	5-20	3,600
W-12-L	16"	10-20	3,600
W-16-L	16"	10-25	3,600
W-12-H	18"	15-50	3,000
W-16-H	18"	15-50	3,000
W-20-L	18"	20-50	3,000
W-25-L	18"	20-25	3,000
W-20-H	24"	25-75	2,800
W-25-H	24"	25-75	2,800
W-30-L	26"	50-100	2,400
W-36-L	26"	50-100	2,400
W-30-H	30"	50-150	1,800
W-36-H	30"	50-150	1,800
W-40-L	30"	50-150	1,800
W-50-L	30"	50-150	1,800
W-60-L	30"	50-150	1,800
W-40-H	40"	60-200	1,200
W-50-H	40"	60-200	1,200
W-60-H	40"	60-200	1,200
